(VAOMI10) 3.5mL IR Cuvette with PTFE Lid, Molded, Round Base, Lightpath 10mm
$98.00
This IR cuvette is for wavelength 250 – 3500 nm, with a path length of 10 mm. Resistant to chemicals. Use up to 1200°C. The price is for 1 piece.
In Stock
Add to Wishlist
CompareAdd to Wishlist
- Type: Molded
Description
VAOMI10 Molded Quartz IR Cuvette is a 2-window IR cuvette with a 10 mm optical path length and 3.5 ml internal volume.
This standard-size cell is widely used in IR and UV/VIS absorbance applications. The molded fabrication offers tighter optical path tolerance and better surface finish, ensuring higher reproducibility in routine spectroscopy. The round base provides broad instrument compatibility, and the PTFE lid offers light coverage for basic protection during measurement.
Key Features
- 10 mm optical path — the most commonly used standard for IR and UV/VIS absorbance measurements.
- 2-window configuration — optimized for transmission experiments with high signal stability.
- Molded fabrication — ensures precise path length and excellent surface quality, suitable for high-accuracy applications.
- PTFE lid — provides basic protection against evaporation and contamination during testing.
- High purity quartz — wide spectral range (250 – 3500 nm), strong resistance to acid and base, and good solvent compatibility.
Typical Applications
- Standard IR and UV/VIS absorbance spectroscopy.
- Routine chemical and environmental analysis.
- Applications requiring high precision in optical path length and signal repeatability.
- Use in solvent-resistant and high-temperature testing environments.
Molded Fabrication Notes
- Produced by molding for precise optical dimensions and smooth internal surfaces.
- Suitable for routine and high-precision spectroscopy.
- PTFE lid is for basic sealing only, not for oxygen isolation or long-term volatile storage.
- Compatible with most solvents except HF and other highly aggressive chemicals.
Cuvette Specifications
| Type | Infrared Quartz Cuvette | Optical Path Length | 10 mm |
| Article No. | VAOMI10 | Volume | 3500 µL |
| Measuring Method | Absorption Cells | Base Type | Round |
| Number of Windows | 2 | Wavelength Range | 250 – 3500 nm |
| Height | 45 mm | Width (Inside) | 10 mm |
| Width (Outside) | 12.5 mm | Depth (Inside) | 10 mm |
| Depth (Outside) | 12.5 mm | Center Height (Z) | 8.5 – 20 mm |
| Fabrication Method | Molded* | Package | Cell & Lid |
Note: Molded fabrication ensures tight tolerance and excellent surface quality. The PTFE lid offers basic coverage but does not fully isolate volatile samples. Avoid using HF and other aggressive solvents to prolong product life.
Comparison of Fabrication Types
| 1 | 2 | 3 | 4 | ||
|---|---|---|---|---|---|
| *Molded | *Fused | *Bonded / Glued | |||
| UV vis ( 190- 2500 nm) | Yes | Yes | Yes | ||
| Transmission Matched | On Request | No | No | ||
| Transmission > 80% | Yes | Yes | Yes | ||
| Resistant to Acids and Bases (except hydrofluoric acid) | Yes | Yes | No | ||
| Resistant to Organic Solvents | Yes | Yes | No | ||
| Usable upto 600°C (1112°F) | Yes | Yes | Yes | ||
| Usable upto 1200°C (2192°F) | Yes | No | No | ||
| 0 Variations Reading | On Request | No | No | ||
| Fabrication | Molded | Assembled with Quartz Powder | Assembled with Glue | ||
| Adhesives | No | No | Yes | ||
| Storage | Short Term Storage | Clean After Use | Clean After Use | ||
| Available Material | Fused Quartz Material | ||||
| Note | Molded and fused cuvettes and cells are assembled by direct fusion without the use of adhesives throughout the production process. This guarantees resistance against corrosive chemicals and high temperature. Each quartz cuvette and cell has excellent transmission from 190nm to 2500nm. | ||||
