(VLF10E) 10 mm Cuvette with 2 Ends Open, Lightpath 10 mm, 2 Windows, Fused
$27.00
This flow-through cuvette is for absorption applications, with a path length of 10 mm. Resistant to most chemicals. Use up to 600°C. The price is for 1 piece.
In Stock
Add to Wishlist
CompareAdd to Wishlist
- Type: Fused
Description
VLF10E Custom Flow Cell is a precision-engineered quartz cuvette designed for UV/VIS absorbance measurements with a 10 mm optical path length and 3.5 mL sample volume. This open-ended flow cell is well-suited for continuous monitoring and in-line analysis in laboratory and industrial setups.
Fabricated using the fused fabrication method, the cuvette offers superior optical clarity, strong chemical resistance, and long-term durability without the use of adhesives. The two clear windows provide a stable and low-noise light path, making this flow cell ideal for high-precision absorbance applications.
Typical Applications
- Continuous-flow UV/VIS absorbance monitoring
- Pharmaceutical and biochemical process analysis
- Environmental and water quality testing
- Inline process control systems
- OEM analytical instrument integration
Key Features
- 10 mm optical path length for precise absorbance measurements
- 3.5 mL chamber volume suitable for flow-through applications
- 2 ends open for easy integration with external flow systems
- Fused fabrication ensures excellent UV/VIS transmission (190–2500 nm)
- Adhesive-free construction for chemical stability and durability
Technical Specifications
| Type | Custom Flow Cell | Optical Path Length | 10 mm |
| Article No. | VLF10E | Volume | 3.5 mL |
| Measuring Method | Absorption Cells | Connector | 2 Ends Open |
| Number of Windows | 2 | Wavelength Range | UV/VIS (190 – 2500 nm) |
| Outside Dimensions | Height 44 mm × Width 12.5 mm × Depth 12.5 mm | ||
| Inside Dimensions | Width 10 mm × Depth 10 mm | ||
| Covers | No | Fabrication Method | Fused* |
| Package | Cell Only | ||
Note: This fused quartz cuvette provides superior optical performance and chemical durability. It is ideal for flow-through absorbance measurements in research, analytical testing, and OEM instrument integration.
Comparison of Fabrication Types
| 1 | 2 | 3 | 4 | ||
|---|---|---|---|---|---|
| *Molded | *Fused | *Bonded / Glued | |||
| UV vis ( 190- 2500 nm) | Yes | Yes | Yes | ||
| Transmission Matched | On Request | No | No | ||
| Transmission > 80% | Yes | Yes | Yes | ||
| Resistant to Acids and Bases (except hydrofluoric acid) | Yes | Yes | No | ||
| Resistant to Organic Solvents | Yes | Yes | No | ||
| Usable upto 600°C (1112°F) | Yes | Yes | Yes | ||
| Usable upto 1200°C (2192°F) | Yes | No | No | ||
| 0 Variations Reading | On Request | No | No | ||
| Fabrication | Molded | Assembled with Quartz Powder | Assembled with Glue | ||
| Adhesives | No | No | Yes | ||
| Storage | Short Term Storage | Clean After Use | Clean After Use | ||
| Available Material | Fused Quartz Material | ||||
| Note | Molded and fused cuvettes and cells are assembled by direct fusion without the use of adhesives throughout the production process. This guarantees resistance against corrosive chemicals and high temperature. Each quartz cuvette and cell has excellent transmission from 190nm to 2500nm. | ||||
