(VALB06) 6uL Cuvette with In/ Outlet Steel Connectors, Pathlength 0.1mm, 2 Windows, Z dim 15mm
$351.00
This flow through cuvette is for micro-volume absorption applications, with a path length of 0.1 mm. For aqueous samples only. Use up to 100°C. The price is for 1 piece.
In Stock
Add to Wishlist
CompareAdd to Wishlist
- Type: Bonded, For aqueous samples only!
Description
VALB06 Ultra-Low Volume Quartz Flow Cuvette is specifically engineered for high-sensitivity UV-Vis absorbance measurements using minimal sample volumes. With an exceptionally short 0.1 mm optical path length and only 6 µL chamber volume, this cuvette enables accurate measurements of highly concentrated solutions while minimizing reagent consumption.
The cell is equipped with stainless steel inlet and outlet connectors, ensuring secure and stable flow control during experiments. Constructed using the Bonded fabrication method, this flow cuvette provides reliable optical performance and cost-effective customization, making it suitable for both routine lab analysis and advanced industrial systems.
Typical Applications
- High-concentration absorbance measurements
- Micro-volume sample analysis
- Continuous-flow monitoring and inline detection
- Pharmaceutical and biochemical R&D
- OEM and automated analytical systems
Key Features
- Extremely short 0.1 mm path length for concentrated sample measurements
- Ultra-low 6 µL internal volume minimizes sample usage
- 2-window design optimized for UV-Vis absorbance
- Stainless steel connectors for stable and secure fluid handling
- Bonded fabrication allows faster customization and lower cost
- UV/VIS transmission range: 190–2500 nm
Technical Specifications
| Type | 6 μL Cuvette | Optical Path Length | 0.1 mm |
| Article No. | VALB06 | Volume | 6 μL |
| Measuring Method | Absorption Cells | Connectors | Stainless Steel |
| Number of Windows | 2 | Wavelength Range | UV/VIS (190 – 2500 nm) |
| Outside Dimensions | Inside Dimensions | ||
| Height | 35 mm | Width | 5 mm |
| Width | 12.5 mm | Depth | 0.1 mm |
| Depth | 12.5 mm | Center Height (Z) | 15 mm |
| Fabrication Method | Bonded* | Package | Cell Only |
Note: Bonded fabrication provides a cost-effective and fast customization option, ideal for specialized flow-through absorbance applications with minimal sample volumes.
Comparison of Fabrication Types
| 1 | 2 | 3 | 4 | ||
|---|---|---|---|---|---|
| *Molded | *Fused | *Bonded / Glued | |||
| UV vis ( 190- 2500 nm) | Yes | Yes | Yes | ||
| Transmission Matched | On Request | No | No | ||
| Transmission > 80% | Yes | Yes | Yes | ||
| Resistant to Acids and Bases (except hydrofluoric acid) | Yes | Yes | No | ||
| Resistant to Organic Solvents | Yes | Yes | No | ||
| Usable upto 600°C (1112°F) | Yes | Yes | Yes | ||
| Usable upto 1200°C (2192°F) | Yes | No | No | ||
| 0 Variations Reading | On Request | No | No | ||
| Fabrication | Molded | Assembled with Quartz Powder | Assembled with Glue | ||
| Adhesives | No | No | Yes | ||
| Storage | Short Term Storage | Clean After Use | Clean After Use | ||
| Available Material | Fused Quartz Material | ||||
| Note | Molded and fused cuvettes and cells are assembled by direct fusion without the use of adhesives throughout the production process. This guarantees resistance against corrosive chemicals and high temperature. Each quartz cuvette and cell has excellent transmission from 190nm to 2500nm. | ||||
