(VFFL30N) 27 mL Μεγάλη κυβέτα, 4 παράθυρα, Χωρίς κάλυμμα, Fused, Lightpath 30mm, 32x34x34 mm
$196.00
Αυτή η φαρδιά διαφανής κυψελίδα τοίχου προορίζεται για εφαρμογές φθορισμού, με μήκος διαδρομής 30 mm. Ανθεκτικό στα περισσότερα χημικά. Χρήση έως 600°C. Η τιμή είναι για 1 τεμάχιο .
Description
Προδιαγραφές κυβετών
1 | 2 | 3 | 4 | |||
---|---|---|---|---|---|---|
Type | 27 ml Cuvette | Optical Path Length | 30 mm | |||
Article No. | VFFL30N | Volume | 27 ml | |||
Measuring Method | Fluorescence Cells | Clear Walls | 32x34 mm | |||
Number of Windows | 4 | Wavelength Range | UV/VIS (190 - 2500 nm) | |||
Outside Dimensions | Inside Dimensions | |||||
Height | 32 mm | Width | 30 mm | |||
Width | 34 mm | Depth | 30 mm | |||
Depth | 34 mm | Cover Material | - | |||
Fabrication Method | Fused* | Package | Cell Only |
Σύγκριση τύπων κατασκευής
1 | 2 | 3 | 4 | ||
---|---|---|---|---|---|
*Molded | *Fused | *Bonded / Glued | |||
UV vis ( 190- 2500 nm) | Yes | Yes | Yes | ||
Transmission Matched | On Request | No | No | ||
Transmission > 80% | Yes | Yes | Yes | ||
Resistant to Acids and Bases (except hydrofluoric acid) | Yes | Yes | No | ||
Resistant to Organic Solvents | Yes | Yes | No | ||
Usable upto 600°C (1112°F) | Yes | Yes | Yes | ||
Usable upto 1200°C (2192°F) | Yes | No | No | ||
0 Variations Reading | On Request | No | No | ||
Fabrication | Molded | Assembled with Quartz Powder | Assembled with Glue | ||
Adhesives | No | No | Yes | ||
Storage | Short Term Storage | Clean After Use | Clean After Use | ||
Available Material | Fused Quartz Material | ||||
Note | Molded and fused cuvettes and cells are assembled by direct fusion without the use of adhesives throughout the production process. This guarantees resistance against corrosive chemicals and high temperature. Each quartz cuvette and cell has excellent transmission from 190nm to 2500nm. |
